Autel Robotics, as a popular competitor of DJI, has attracted much attention for its EVO series of drones, especially the Nano and Lite series that debuted at the 2022 ces exhibition. It has become the best in the world, and won the German if red dot design award.
First take a look at the Autel EVO series of drone products, you must be curious, why Autel Drone has become a competitor of DJI, and what is the amazing performance of Autel Robotics?
Autel EVO series drones are divided into EVO Nano series, EVO Lite series, and EVO II series. The first two are called consumer drones. The EVO II series has many products, some of which are classified as consumer drones. Drones, some classified as enterprise drones.
Autel EVO Nano Series Drones Compare
Autel Robotics EVO Nano series drones are divided into two drones, Autel Robotics EVO Nano drone and Autel Robotics EVO Nano plus drone, each drone has two package combinations, EVO Nano standard bundle and EVO Nano Premium Bundle, EVO Nano Plus Standard Bundle and EVO Nano Plus Premium Bundle. No matter how we choose the drone kit, the more important point is how to get more essential accessories.
Nano Drone and Nano Plus Drone have the same body performance. The biggest difference is the inconsistency of camera parameters. The level of camera performance plays a decisive role in the quality of photo imaging. Let's see if Nano Drone vs Nano Plus has no difference. man-machine.
| Specification | EVO Nano | EVO Nano Plus | |
| Similarities | Take Off Weight | 249g | 249g |
|
Maximum Takeoff Altitude |
4000 meters | 4000 meters | |
| Flight Time | 28 minutes | 28 minutes | |
| Maximum Wind resistance | level 5 | level 5 | |
| Satellite Navigation System | GPS | GPS | |
| Perception System | Three-way obstacle avoidance | Three-way obstacle avoidance | |
| On-board Memory | none | none | |
| Gimbal | Three-axis gimbal | Three-axis gimbal | |
| Digital Zoom | 1 ~ 16 times | 1 ~ 16 times | |
| Maximum Signal Effective Distance | 10km | 10km | |
| Difference |
Camera Sensor |
1/2" CMOS, 48 million | 1/1.28 inches 50 million |
| Aperture | f/2.8 | f/1.9 | |
| ISO Range | 100-3200 | 100-6400 | |
|
Maximum Photo Size
|
48 million: 8000x6000 (4:3) 12 million: 4000x3000 (4:3) 4K: 3840x2160 (16:9) |
50 million: 8192x6144 (4:3) 12.5 million: 4096x3072 (4:3) 4K: 3840x2160 (16:9) |
|
| Video Resolution | 3840x2160p30/25/24 2720x1528 p30/25/24 1920x1080p60/50/48/30/25/24 |
3840x2160p30/25/24 2720x1528 p30/25/24 1920x1080p60/50/48/30/25/24 |
Autel EVO Lite Series Drones Compare
The Autel Robotics EVO Lite range of drones is divided into two drones, the Autel Robotics EVO Lite Drone and the Autel Robotics EVO Lite Plus Drone, each with two package combinations, the EVO Lite Standard Bundle and EVO Lite Premium Bundle, EVO Lite Plus Standard Bundle and EVO Lite Plus Premium Bundle.
Like the Nano series drones, the Lite series drones have the same body performance. The biggest difference is the inconsistency of camera parameters. The biggest difference between EVO Lite and EVO Lite+ is vertical imaging. Autel EVO Lite drone is the world's first drone. Model 4-axis gimbal camera drone, see more here.
| Specification | EVO Lite | EVO Lite Plus | |
| Similarities | Take Off Weight | 820g | 820g |
|
Maximum Takeoff Altitude |
5000 meters | 5000 meters | |
| Flight Time | 40 minutes | 40 minutes | |
| Maximum Wind resistance | level 7 | level 7 | |
| Satellite Navigation System | GPS | GPS | |
| Perception System | Three-way obstacle avoidance | Three-way obstacle avoidance | |
| On-board Memory | none | none | |
| Gimbal | four-axis gimbal | Three-axis gimbal | |
| Digital Zoom | 1 ~ 16 times | 1 ~ 16 times | |
| Maximum Signal Effective Distance | 12km | 12km | |
| Difference |
Camera Sensor |
1/1.28" CMOS, 50 million | 1 inches 20 million |
| Aperture | f/1.9 | f/2.8-f11 | |
| ISO Range | 100-6400 | 100-6400 | |
|
Maximum Photo Size
|
50 million: 8192x6144 (4:3) 12.5 million: 4096x3072 (4:3) 4K: 3840x2160 (16:9) |
5472x3648 (3:2) |
|
| Video Resolution | 3840x2160 p60/50/48/30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p120/60/50/48/30/25/24 |
5472x3076 p30/25/24 3840x2160 p60/50/48/30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p120/60/50/48/30/25/24 |
Autel EVO II Series Drones Compare
Autel Robotics EVO II series drones far surpass the previous two series drones in flight performance and camera configuration, and are prepared for real pilots and photographers. Autel Robotics EVO II consumer series has EVO II 8k camera drone and EVO II Pro 6k Camera Drone, EVO II enterprise series has EVO II Enterprise, EVO II RTK Series, EVO II DUAL 640T. In the configuration of powerful performance, these drones still adopt a foldable design, allowing pilots to start a beautiful journey.
In the Autelpilot store, we present to you the EVO II Pro 6k drone and the EVO II Dual 640T drone, it is foreseeable that the EVO II series of drones will be even more powerful.
| Specification | EVO II Pro |
EVO II Dual 640T |
|
| Similarities | Take Off Weight | 1191g | 1150g |
|
Maximum Takeoff Altitude |
7000 meters | 7000 meters | |
| Flight Time | 40 minutes | 40 minutes | |
| Maximum Wind resistance | level 8 | level 8 | |
| Satellite Navigation System | GPS/GLONASS/VIO/ATTI | GPS/GLONASS/VIO/ATTI | |
| Perception System | 12 azimuth obstacle avoidance | 12 azimuth obstacle avoidance | |
| On-board Memory | 8GB | 8 GB | |
| Gimbal | Three-axis gimbal | Three-axis gimbal | |
| Digital Zoom | 1~8 times(4x lossless zoom) | 1~8 times(4x lossless zoom) | |
| Maximum Signal Effective Distance | 9km | 9km | |
| Difference |
Camera Sensor |
1 inches 20 million | 1 inches 48million |
| Aperture | f/2.8-f11 | f/1.8 | |
| ISO Range | 100-6400-12800 | 100-3200 | |
|
Maximum Photo Size
|
5472x3648 (3:2) 5472x3076 (16:9) 3840x2160 (16:9) |
8000x6000 (4:3) |
|
| Video Resolution | 6K 5472*3076 p30/p25/p24 4K 3840*2160 p60/p50/p48/p30/p25/p24 2.7K 2720*1528 p120/p60/p50/p48/p30/p25/p24 1080P 1920*1080 p120/p60/p50/p48/p30/p25/p24 |
7680x4320 p25/p24 5760x3240 p30/p25/p24 3840x2160 p60/p50/p48/p30/p25/p24 2720x1528 p120/p60/p50/p48/p30/p25/p24 1920x1080 p120/p60/p50/p48/p30/p25/p24 |
EVO II Pro 6k Drone Rugged Bundle maximizes the combined benefits of drones and accessories. Autel EVO II Pro 6k drone, as a high-end camera drone, takes the picture to the extreme, and the 6k picture is the same as the 4k picture. A must-have for filmmakers when it comes to more saturated colors and sharper images. Also the Autel EVO II Pro 6k drone's camera lenses are interchangeable, which means we'll achieve more Features.
The EVO II Dual 640T drone is not only a camera drone, but also a thermal imaging function. As an 8k drone, the Autel EVO II Dual 640T is equipped with a 640*512/ 320*256 FLIR BOSON Sensor thermal imager. Shooting in medium-picture mode will be more used in dangerous scenes, such as building inspections, industrial inspections, fire rescues, wildlife rescues, etc. Drones will better help us reduce the potential dangers of people and property.
Autel EVO Max Series Drones Compare
The Autel EVO Max series is a new generation of intelligent drones launched by Autel Robotics in 2023, targeting commercial and industrial applications. It integrates a number of industry-leading technologies to provide users with an efficient, safe and versatile flight experience.
The Autel EVO Max series includes EVO MAX 4T, EVO MAX 4N, EVO MAX 4TXE. All three drones have a long endurance of 42 minutes, a long-range image transmission of 20 kilometers, 720° omnidirectional obstacle avoidance, strong anti-interference capabilities and the core features of A-Mesh 1.0 network technology. The difference lies in the camera payload.
EVO Max 4T Camera Payload: Four cameras are integrated, including a 48MP wide-angle camera (1/2-inch CMOS, supporting 4K video), a 48MP telephoto camera (supporting 10x optical zoom and 160x hybrid zoom), a 640×512 thermal imaging camera (16x digital zoom, temperature range -20°C to 550°C), and a laser rangefinder (ranging range 5-1200 meters, accuracy 1 meter).
EVO Max 4T XE Camera Payload: Similar to 4T, but the telephoto camera is upgraded to 4K 10x continuous optical zoom, suitable for tasks that require higher zoom capabilities.
EVO Max 4N camera payload: equipped with a starlight-level night vision camera (0.0001 LUX, supports ISO up to 450000), a 50MP wide-angle camera (1/1.28-inch CMOS, supports 4K video), a 640×512 thermal imaging camera and a laser rangefinder.
Autel EVO Lite Enterprise Series Drones Compare
(1) EVO Lite 640T Enterprise
Camera payload:
Dual-lens system: includes a 48MP wide-angle visible light camera (1/2-inch CMOS sensor, supports 4K video, 16x digital zoom) and a 640×512 thermal imaging camera (temperature range -20°C to 550°C, 16x digital zoom).
Application scenarios: The thermal imaging function makes it particularly suitable for tasks that require temperature measurement and thermal data, such as soil temperature detection and irrigation optimization in agriculture, or night search and rescue and fire monitoring in public safety.
Features: The visible light camera provides clear images, and the thermal imaging camera assists decision-making, suitable for multi-scenario applications.
(2) EVO Lite 6K Enterprise
Camera payload:
6K visible light camera: equipped with a 1-inch CMOS sensor, supports 6K video recording and 20MP photo shooting, and has excellent low-light performance (ISO up to 48000).
Application scenarios: Suitable for tasks that require high-resolution images, such as crop health monitoring in agriculture, terrain mapping, or spring aerial photography in film and television shooting.
Features: Its high-sensitivity camera can capture clear images even in low-light environments, making it suitable for night patrols, search and rescue, and other tasks.
Summary
At present, Autel Robotics' drone business is constantly expanding. In the process of innovation, we are constantly discovering the advantages and disadvantages of drones. Autel EVO series drones are the core product line of Autel Robotics, including EVO II series, EVO Lite series, EVO Max series and EVO Lite Enterprise series, etc., with positioning from consumer to enterprise level, covering photography, agricultural mapping, industrial inspection, public safety and other fields.
Let us continue to pay attention to Autel EVO series drones and explore the future.
