Autel EVO Lite 640T Enterprise

$3,359.00

Autel EVO Lite 640T Enterprise

Name: Autel EVO Lite 640T Enterprise
Brand: Autel Robotics
SKU: B-M341-01+C-M035-00+B-M012-00
Price: 3359.0 USD
Availability: InStock
Rating: 5 (2 reviews)

$3,359.00

In Stock - Ships within 12 hrs

Free Set of Propeller Guards and Landing Pad
Lightweight and Portable
Easy Operation
High-Precision Visual Navigation
Dual-Binocular Obstacle Avoidance in Three Directions
1- 16x digital zoom
640*512 Infrared Thermal Imaging
AI Target Recognition and Positioning
12 km Transmission Range
40 Minutes of Flight Time

Delivered by Sat, Sep 21 - Mon, Sep 23 Ship from USA

Service

Fast, Free Shipping & No Extra Tax

30-Day Return or Replacement

12-Month Free Warranty

Lifetime Customer Support

Pay with Ease

Trusted Delivery

Overview
Specs
In the box
Downloads
Videos

Autel EVO Lite 640T Enterprise

Autel EVO Lite Enterprise Series, by Autel Robotics, offers multiple advantages such as a lightweight and portable design, rapid deployment, and simple control for industrial applications. The AI target recognition feature enables the aircraft to easily identify and map various target objects automatically. The three-way binocular vision obstacle avoidance provides a safe flying experience.

2024 Autel EVO Lite 640T Enterprise features a dual gimbal system, with a visible-light camera providing clear and detailed images, while the thermal-imaging camera aids in decision-making during operations. Paired with the Autel Enterprise professional flight software, Lite 640T offers easy operation, user-friendly interaction, flexible single-person deployment, and efficient application in scenarios such as public safety and emergency rescue.
- Lightweight and Portable
- Simple Control
- AI Target Recognition
- 6K Resolution
- 640*512 Infrared
  Thermal Imaging
- 12km Video
  Transmission Rang
- Three-Way
  Binocular Vision Obstacle Avoidance
- 40-Minute
  Flight Endurance
- Lightweight and Portable
- Simple Control
- AI Target Recognition
- 6K Resolution
- 640*512 Infrared
  Thermal Imaging
- 12km Video
  Transmission Rang
- Three-Way
  Binocular Vision Obstacle Avoidance
- 40-Minute
  Flight Endurance
Lightweight and Portable

Autel EVO Lite Enterprise Series aircraft weigh only 866 grams and have folded dimensions of just 210*123*95mm, making them easy to carry in a backpack. With a simple operation, they are ideal for efficient execution of missions by a single operator.

Autel Enterprise App

Autel Enterprise is a professional flight mission software designed for industry applications by Autel Robotics. It features an optimized interaction design for simple and efficient operation, an editable toolbar design for intuitive use, and integrates intelligent and professional functions to fully utilize the industry value of Autel EVO Lite Enterprise Series aircraft.
- - Split-Screen Display

    Visible light, infrared, or map support dual-channel simultaneous output on the screen, providing comprehensive information through comparison.
- - Customizable Toolbar

    Customize the menu toolbar in the app for quick access to frequently used functions, meeting personalized usage needs.
- - Offline Maps

    Addresses the issue of map loading failures in no-network or weak-network environments by supporting offline maps, aiding in precise flight positioning.
- - Split-Screen Display

    Visible light, infrared, or map support dual-channel simultaneous output on the screen, providing comprehensive information through comparison.
  - Customizable Toolbar

    Customize the menu toolbar in the app for quick access to frequently used functions, meeting personalized usage needs.
  - Offline Maps

    Addresses the issue of map loading failures in no-network or weak-network environments by supporting offline maps, aiding in precise flight positioning.
AI Target Recognition and Positioning

Utilizing wide-angle or infrared lenses combined with intelligent AI algorithms and a self-learning system, the aircraft can automatically recognize and locate, including people, cars, and boats, projecting their positions on the map.

Data Security with Multiple Protections
- - Privacy Protection

    Flight logs, locations, and other user privacy data require user consent to upload.
- - Encrypted Storage

    Supports AES encryption for photos, videos, and flight logs, requiring a password for access.
- - Video Live Streaming

    Supports RTMP and GB28181* protocols for live streaming, allowing for remote real-time viewing and analysis.

    *The GB28181 video live streaming protocol feature is pending future updates.
- - Privacy Protection

    Flight logs, locations, and other user privacy data require user consent to upload.
  - Encrypted Storage

    Autel EVO Lite Enterprise SeriesSupports AES encryption for photos, videos, and flight logs, requiring a password for access.
  - Video Live Streaming

    Lite Enterprise Supports RTMP and GB28181* protocols for live streaming, allowing for remote real-time viewing and analysis. *The GB28181 video live streaming protocol feature is pending future updates.
EVO Lite 640T Enterprise

EVO Lite 640T is equipped with a dual gimbal, the wide-angle visible-light camera offers a broad field of view with vivid high-definition images, while the infrared thermal-imaging camera integrates high-resolution thermal-imaging algorithms, providing clear and detailed thermal source identification.

Thermal-Imaging
Camera

Visible-Light
Camera
- 640*512 resolution
- 9.1 mm focal length
- 16x digital zoom
- Temperature measurement range:
  -20°C to 150°C / 0°C to 550°C
- Temperature accuracy:
  ±3°C or ±3% of reading (whichever is greater)
- 48 million pixels
- F2.8 aperture
- 16x digital zoom
- Maximum photo size of 8000*6000
- Maximum video resolution of 4K 30P
High-Definition Video Transmission

Equipped with Autel SkyLink image transmission technology for a dual-signal, dual-reception system, the image transmission anti-interference capability improved, and the transmission distance reaches up to 12 kilometers. It supports 2.4GHz/5.2GHz/5.8GHz adaptive frequency hopping transmission, automatically selecting the best channel based on electromagnetic interference, providing strong anti-interference capability.
- 12 kilometers

  Image transmission distance
- 1080P/30FPS

  Real-time image transmission quality
- <200 milliseconds

  Latency
- 2.4GHz/5.2GHz/5.8GHz

  Frequency band transmission
- 12 kilometers

  Image transmission distance
- 1080P/30FPS

  Real-time image transmission quality
- <200 milliseconds

  Latency
- 2.4GHz/5.2GHz/5.8GHz

  Frequency band transmission
Visual Perception System

Autel Robotics EVO Lite Enterprise 2024 is equipped with wide-angle vision sensors at the front, back, and bottom, ensuring reliable flight safety.

SDK Ecosystem
- - Mobile SDK
  - The open Mobile SDK provides efficient, versatile, and easy-to-use control and service interfaces, enhancing development efficiency and enabling the creation of custom solution scenarios.
- - Mobile SDK
  - Open UX SDK (iOS/Android) can directly call up the ready-made interactive interface.
Flight Performance

Born small but mighty. The outstanding flight performance of Autel EVO Lite Enterprise Series drones effortlessly tackles various challenges across multiple scenarios, significantly enhancing the efficiency of single-person mission flights.

Accessories
- - Autel Smart Controller SE V2

    Display: 6 inches, maximum brightness of 800nits, 1440*720 resolution. Battery life: Removable battery design, 1.5 hours of battery life, supports hot swapping for continuous operation. Storage: Built-in 32G storage space, supports 128G microSD card to expand storage space. Environmental adaptability: Operating temperature range from -10℃ to 40℃.
  - Remote Controller Multi-Charging Kit (Optional)

    The kit includes three remote controller batteries and one multi-port charger, meeting the needs of long-duration operations. The remote controller multi-port charger supports charging up to four remote controller batteries simultaneously.
  - Smart Multi-Charging (Optional)

    With 200W fast charging, it supports simultaneously charging three drone batteries and one remote controller battery. *This accessory will be launched later
- - Autel Smart Controller SE V2

    Display: 6 inches, maximum brightness of 800nits, 1440*720 resolution. Battery life: Removable battery design, 1.5 hours of battery life, supports hot swapping for continuous operation. Storage: Built-in 32G storage space, supports 128G microSD card to expand storage space. Environmental adaptability: Operating temperature range from -10℃ to 40℃.
  - Remote Controller Multi-Charging Kit (Optional)

    The kit includes three remote controller batteries and one multi-port charger, meeting the needs of long-duration operations. The remote controller multi-port charger supports charging up to four remote controller batteries simultaneously.
  - Smart Multi-Charging (Optional)

    With 200W fast charging, it supports simultaneously charging three drone batteries and one remote controller battery. *This accessory will be launched later
Applications
- - Law Enforcement
- - Security Patrol
- - Emergency Rescue
- - Law Enforcement
  - Security Patrol
  - Emergency Rescue

Autel Robotics EVO Lite 640T Enterprise Teachnical Specifications

Aircraft

Visual Perception System

Image Transmission

EVO Lite 640T Enterprise - Visible Light Camera

EVO Lite 640T Enterprise - Thermal Imaging Camera

EVO Lite 640T Enterprise Gimbal

Autel Smart Controller SE V2

Autel Smart Controller SE V2 - Image Transmission

Autel Smart Controller SE V2 - Display

Autel Smart Controller SE V2 - Battery

Smart Battery

Battery Storage

Battery Charger

Autel EVO Lite 640T Enterprise Package List

Name	Download
Autel EVO Lite Enterprise Series Aircraft User Manual
Autel EVO Lite Enterprise Series Basic Combo Packing List
Autel EVO Lite Enterprise Series Plus Combo Packing List
Autel EVO Lite Enterprise Series Quick Start Guide

Best Recommend

Autel Robotics EVO Lite Propeller for Lite/ Lite+ Drones (Pair)

Sold out

Autel Robotics EVO Lite Series Propeller Guards

$19.00

Autel Robotics EVO Lite/ Lite+ Battery

Sold out

Autel EVO Lite 6K Enterprise

$1,579.00

Weight	866 g
Maximum takeoff weight	866 g
Dimensions	210×123×95mm (folded, propellers included) 433×516×95mm (unfolded, propellers included)
Max. rotation speed	8000 rpm
Wheelbase	368 mm
Propeller Dimension	8.5 inch injection molded propeller. Spec: 8530
Propeller weight	7.5 g
Maximum ascent speed	Slow:3 m/s Smooth:3 m/s Standard: 5 m/s Ludicrous: 6 m/s
Maximum descent speed	Slow:3 m/s Smooth:2 m/s Standard: 3 m/s Ludicrous: 4 m/s
Maximum horizontal flight speed (no wind near sea level)	Slow :3 m/s Smooth:5 m/s Standard: 10 m/s Ludicrous: 18 m/s
Maximum Service Ceiling Above Sea Level	3000 meters
Maximum flight altitude	Chinese Mainland or EU: no more than 120 meters US: no more than 400 feet Note: In the flight application UAV, it can be set from 0 to 800 meters. To set beyond height required by law, you need to obtain authorization from authority.
Maximum flight time (no wind)	40 minutes Note: Tested in lab with nearly no wind when aircraft flies at speed of 10 m/s and only for reference.
Maximum flight mileage	24 km
Maximum hover time (no wind)	37 minutes Note: Tested in lab with nearly no wind when aircraft hovers and only for reference.
Maximum wind resistance level	Fresh breeze
Maximum tilt angle	Slow: 15° Smooth: 30° Standard: 30° Ludicrous: 33°
Maximum rotation angular speed	Smooth: 60°/s Standard: 120°/s Ludicrous: 200°/s
Working temperature	-10℃~40℃
Battery hot replacement	Not support
Internal storage	Onboard storage: 4GB (support microSD card of up to 256GB)
GNSS	GPS/BDS/GLONASS
Hover accuracy	Vertically: ±0.1 meters (when visual positioning is working normally) ±0.3 meters (when GNSS is working normally) Horizontally: ±0.15 meters (when visual positioning is working normally) ±0.3 meters (when GNSS is working normally)

Sensing range	Forward: 0.2~23 meters Effective obstacle avoidance speed: ＜10m/s Backward: 0.2~30 meters Effective obstacle avoidance speed: ＜10m/s Downward: 0.2~20 meters
FOV	Forward: 75° horizontally, 87° vertically Backward: 35° horizontally, 45° vertically Downward: 99° horizontally, 83° vertically
Effective use of the environment	Front, rear: The surface has rich texture and sufficient lighting conditions (>15 lux, normal indoor fluorescent lighting environment) Below: The ground is richly textured and the lighting conditions are sufficient (>15 lux, normal indoor fluorescent lighting environment) The surface is made of diffuse reflective material and the reflectivity is >20% (such as walls, trees, people, etc.)

Operating Frequency	2.4G: 2.400 – 2.476 GHz; 2.400 – 2.4835 GHz* 5.2G: 5.15 - 5.25 GHz*** 5.8G: 5.725 - 5.829 GHz, 5.725 - 5.850GHz* Only applies to SRRC regions Only applies to FCC, ISED, CE, UKCA and RCM regions **Only applies to FCC regions Note: Some frequencies are only available in some regions and some frequencies are only allowed for indoor use. Check local laws and regulations for details.
Maximum signal effective distance (No interference, no obstruction)	FCC: 12 kilometers CE: 6 kilometers
Effective transmitter power ( EIRP)	2.4G: ≤30dBm (FCC/ISED/RCM); ≤20dBm(CE/SRRC/UKCA) 5.2G: ≤30dBm (FCC) 5.8G: ≤30dBm(FCC/SRRC/ISED/RCM); ≤14dBm(CE)

Image sensor	1/2 inch CMOS, 48 million pixels
Lens	Field of view: 83.4° focal length: 24 mm Aperture: f/2.8 Focus distance: 0.5 meter ~ ∞ Focus: FF (Fixed Focus)
ISO range	Auto Mode: ISO100 ~ ISO6400 Manual Mode: Video: ISO100 ~ ISO6400 Photo: ISO100 ~ ISO6400 Night scene mode: ISO100 ~ ISO32000
Shutter speed	Photo mode: 1/8000 ~ 0.5 seconds Others: 1/8000 ~ 1/30 seconds
Defog mode	Support
Zoom	1 - 16x digital zoom
Maximum photo size	3840×2160 P30 1920×1080 P30
Photo format	JPG
Photo shooting mode	Single shooting
Video resolution	3840×2160 P30 1920×1080 P30
Video format	MP4/MOV
Video coding format	H.265/H.264
Video maximum bit rate	100Mbps
Support file system	FAT32/exFAT

Image Sensor	Uncooled VOx Microbolometer
Lens	FOV: 61° Focal length: 9.1 mm Aperture: f/1.0 Focusing distance: 2.2 m ~ ∞
Sensitivity	≤50mK@f/1.0, 25°C
Pixel Pitch	12um
Wavelength	8 - 14um
Radiometric Measurement Method	Center measurement/Pot measurement/Rectangular measurement
Radiometric Temperature Range	-20°C to 150°C (high gain mode); 0 to 550°C (low gain mode)
Radiometric Measurement Accuracy	±3°C or reading ±3% (using the larger value) @ ambient temperature ranges from -20°C to 60°C
Accurate Temperature Measurement Distance	1 ~ 25 m
Digital Zoom	16x digital zoom
Temperature Alert	High and low temperature alarm thresholds, Reporting coordinates and temperature values
Palette	White Hot/Black Hot/Searing/ Rainbow/Grey/Ironbow/Cold and Hot
Photo Size	640×512
Photo Format	JPG (the images contain temperature information and are parsed by dedicated SDK and PC tools)
Photo Taking Mode	Auto
Video Resolution	640×512@30FPS
Video Format	MP4
