DJI has launched the new Matrice 4 series of industrial drones, including Matrice 4T and Matrice 4E, which are on par with the Autel EVO Max series released in 2023, providing infrared imaging, day and night image capture and improved visual quality, and is a leader in commercial drones.
What is the DJI Matrice 4 series?
The DJI Matrice 4 series is a new compact and intelligent multi-sensor flagship drone series built for the enterprise industry. The series includes Matrice 4T and Matrice 4E, multi-sensor cameras provide clear visual images, laser rangefinders, intelligent detection, and aerial payloads all provide greater possibilities for drone operations, which can be applied to a wide range of industries such as power, emergency response, public safety and forestry protection.
What is the Autel EVO MAX series?
The Autel EVO MAX series is a powerful and compact flagship drone built for a variety of complex environments. Autel EVO MAX series includes EVO MAX 4T, EVO MAX 4T XE and EVO MAX 4E.
The EVO Max series uses the industry's first A-Mesh networking technology, which allows multiple devices to be freely networked between drones, drones and ground terminals, and supports multiple modes such as "one machine and multiple machines" and "master-slave dual control". The EVO Max series also includes 720° obstacle avoidance, high-precision visual navigation, super zoom camera, super starlight-level night vision camera and 15km HD video transmission.
Camera gimbal: DJI Matrice 4T vs. Autel EVO MAX 4Txe
| EVO MAX 4Txe | DJI Matrice 4T |
|
Wide-Angle Camera 1/1.2″ CMOS, 48MP Effective Pixels, f/1.2.8, Format Equivalent: 24 mm, DFOV: 83.4° Zoom Camera 1/1.2″ CMOS, 48MP Effective Pixels, f/2.8-f/4.8, 10x Optical Zoom, 160x Max. Hybird Zoom, Video Resolution:4000*3000 30fps, Phote Size: 4000*3000, 8000*6000 Laser Range Finder Measuring Rnage: 5-1200m(16.4-3737 ft) Measurement Accuracy: ±(1m+D*0.15%) *where D is the distance to a vertical reflecting plane Infrared Thermal Camera 640*512 resolution, 9.1 mm focal length, 16x digital zoom, Range: -4℉ to 1.22 ℉, Temperature accuracy: ±2℃ or reading 2℃ |
Wide-Angle Camera 1/1.3″ CMOS, 48MP Effective Pixels, f/1.7, Format Equivalent: 24 mm Medium Tele Camera 1/1.3″ CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 70 mm Tele Camera 1/1.5″ CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 168 mm Laser Range Finder Measurement Range: 1800 m (1 Hz); Oblique Incidence Range (1:5 Oblique Distance): 600 m (1 Hz) Blind Zone: 1 m; Range Accuracy (m): ± (0.2 + 0.0015 × D) Infrared Thermal Camera Resolution 640 × 512, f/1.0, Equivalent Focal Length: 53 mm, Uncooled VOx Microbolometer, Supports High-Res Mode NIR Auxiliary Light FOV: 6°, Illumination Distance: 100 m |
Camera gimbal: DJI Matrice 4E vs. Autel EVO MAX 4E
| EVO MAX 4E | DJI Matrice 4E |
|
Wide-Angle Camera 50MP, 1/1.28" CMOS, Video Resolution: 3840*2160, 4K 30fps, max ls0 64000 Starlight Camera ISO Range:100-450000Phote Resolution:1920*1200Video Resolution:1920*1200P30 Infrared Thermal Camera 640*512 resolution, 9.1 mm focal length, 16x digital zoom, Range: -4℉ to 1.22 ℉, Temperature accuracy: ±2℃ or reading 2℃ Laser Range Finder Measuring Rnage: 5-1200m(16.4-3737 ft) Measurement Accuracy: ±(1m+D*0.15%) *where D is the distance to a vertical reflecting plane |
Wide-Angle Camera 4/3 CMOS, 20MP Effective Pixels , f/2.8-f/11, Format Equivalent: 24 mm, Mechanical Shutter Medium Tele Camera 1/1.3″ CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 70 mm Tele Camera 1/1.5″ CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 168 mm Laser Range Finder Measurement Range: 1800 m (1 Hz); Oblique Incidence Range (1:5 Oblique Distance): 600 m (1 Hz) Blind Zone: 1 m; Range Accuracy (m): ± (0.2 + 0.0015 × D) |
Autel EVO MAX series and DJI Matrice 4 Series usher in a new era of intelligent aerial operations.
