Autel EVO MAX 4T FAQ

Autel EVO MAX 4T FAQ

What is Autel EVO MAX 4T?

The Autel EVO MAX 4T is a new addition to the Autel Robotics Enterprise series, featuring a multi-camera hybrid zoom camera with 10x optical and 160x digital zoom, 4K video and a thermal camera. It also includes a laser rangefinder, millimeter-wave radar, autonomous flight technology, omnidirectional obstacle avoidance and technology to suppress radio interference.

Autel EVO Max 4T is designed for safety and reliability, with foldable wings, 15-second fast take-off, IP43 waterproof and dustproof rating, take-off and landing can withstand wind speeds up to 27 miles per hour. In addition, it has multiple mission planning and is the first to use the A-Mesh system to realize the collaborative operation of multiple drones.

When was the Autel EVO MAX 4T released?

The Autel EVO Max 4T is an enterprise drone announced by Autel Robotics at CES 2023 on Jan. 5 (10 a.m. ET).

Features of Autel EVO MAX 4T

Autel Max 4T
  • No Blind Spots
  • Anti Jam
  • Anti Interference
  • 15s Take Off
  • 8K 10x Optical Zoom
  • IP43 Weather Rating
  • Hot-Swappable Batteries
  • Navigation In GPS Denied Environments
  • 4 miles Transmission Range
  • 42 mins Max. Flight Time
  • 720° Obstacle Avoidance

What is the configuration of Autel EVO Max 4T camera?

EVO Max 4T is equipped with three high-quality cameras: a telephoto camera, a wide-angle camera, and an infrared thermal imaging camera.

Autel MAX 4T Camera

Zoom camera: with 10x optical zoom, 160x digital zoom, 1/2 inch CMOS sensor, aperture size f/2.8-f/4.8, can take 48MP photos, maximum photo resolution 8000*6000, maximum video resolution 7680*4320.

Wide camera Camera: 1/1.28″ CMOS sensor, fixed aperture f/1.9, using PDAF to focus, can take a maximum of 50MP photos, the maximum resolution of photos is 8192*6144, and the maximum resolution of videos is 3840*2160.

Infrared thermal imaging camera: Infrared thermal imaging resolution is 640×512@30fps, fixed aperture f/1.2, focal length 13mm, pixel pitch 12 microns, temperature range can reach -4℉ to 302℉, 32℉ to 1022℉.

In addition, EVO Max 4T also integrates a laser rangefinder, which is on the same camera platform as the three cameras. The measurement accuracy of the laser rangefinder is ±1 meter, and the measurement range can reach 1.2 kilometers.

Does EVO Max 4T support temperature measurement?

Yes, it is equipped with a temperature analysis tool - IR PC TOOL. The resolution of the thermal imager of EVO Max 4T can reach 640*512@30fps, realize 16x digital zoom, and the measuring distance can reach 1.2 kilometers.

Does EVO Max 4T support nighttime obstacle avoidance and water surface obstacle avoidance?

Yes, the millimeter-wave radar carried by the aircraft realizes obstacle avoidance at night and surface obstacle avoidance. Surrounded by obstacle sensors, the Max 4T is able to map its environment and automatically navigate around obstacles. The Max 4T has 720° obstacle avoidance and can detect objects down to 0.5 inches.

What is the difference between 4D mode and 3D mode of EVO Max 4T millimeter wave radar?

In 4D mode, the radar can detect objects from four parts: distance, speed, yaw angle and pitch angle, and the speed measurement range is ±60m/s. In 3D mode, the radar can detect objects from three parts: distance, speed and yaw angle, and the speed range is ±28m/s.

Is the EVO Max 4T dust and water resistant?

Yes, the EVO Max 4T is rated IP43.

IP43 for Autel Max 4T

What are the updates in SkyLink 3.0 compared to SkyLink 2.0?

Autel drones use the self-developed Autel Skylink transmission system, SkyLink 2.0 is used in Autel EVO II V3 series, the transmission distance is 15 kilometers, and it supports three-band (2.4/5.8Ghz/900Mhz) transmission. Autel SkyLink 3.0 has a longer transmission distance of up to 20 kilometers, supports more frequency bands (2.4/5.2/5.8Ghz/900Mhz), and has stronger anti-radio frequency interference capabilities.

Autel SkyLink 3.0

What is the maximum flight time of the EVO Max 4T?

The flight time of the quadcopter drone depends on the power system of the drone and the take-off weight of the drone is the longest. The EVO Max 4T weighs around 1600g and has a flight time of 42 minutes (without load).

What software does Autel EVO MAX 4T use?

Currently Autel EVO Max 4T is only available for Autel Enterprise App.

Autel Enterprise App

What remote control does Autel EVO MAX 4T use?

Currently Autel MAX 4T only works with Autel Smart Controller V3.

Autel Smart Controller V3





*Autelpilot will continue to pay attention to EVO Max 4T and update more answers to questions related to EVO Max 4T.
