Thermal imaging drones refer to drones equipped with infrared thermal imaging cameras. Based on the characteristics of thermal imaging, thermal imaging drones can be used in a variety of environments, bringing convenience to all walks of life. Here we explain the best thermal imaging drones of 2024.
The Best Infrared Thermal Imaging Drones of 2024
How to Review the Best Thermal Imaging Drones? We will illustrate these thermal imaging drones by comparing their specifications, performance and usability. They are Autel EVO MAX 4T, Autel EVO II Dual 640T V3, DJI Mavic 30T, DJI Mavic 3T, DJI P4 Multispectral, DJI Mavic 2 Industry Edition.
Autel EVO MAX 4T
Autel EVO MAX 4T is currently Autel Robotics' leading commercial drone, a semi-autonomous mission drone, with foldability, super anti-interference ability, omnidirectional obstacle avoidance, flight time of up to 42 minutes, the longest The remote control distance is 20km, and it can be connected to SDK tasks.
The superiority of Autel EVO MAX 4T is that it has a multi-sensor camera gimbal, which integrates a wide-angle camera, a zoom camera, a thermal imager, and a laser rangefinder. It can achieve a maximum of 8k 10x optical zoom, and the thermal imager can reach 640*512@30fps resolution, enhanced real-time viewfinder, support simultaneous output of RGB, infrared, night vision, and wide-angle images.
Autel EVO MAX 4T adopts Autel Smart Controller V3 and works with Autel Enterprise App. It can also perform intelligent tracking and lock the target under the thermal image.
Autel EVO II Dual 640T V3
Autel EVO II Dual 640T V3 is an upgraded version based on Autel EVO II Dual 640T V2. The difference between the two is the difference in the camera sensor, but the body performance remains the same.
Autel EVO II Dual 640T V3 has dual cameras, the RGB camera can shoot 8K@25fps video, 1/1.28 inch CMOS, the resolution of the thermal imager can reach 640*512@30fps, it is foldable, the RGB camera and the thermal imager can be Form a picture-in-picture mode, display 10 hot color palettes, the maximum flight time is 38 minutes, and the remote control distance is 15km.
DJI Matrice 30T
DJI Matrice 30T is also a leader among commercial drones. It is a multi-sensor camera drone with a large volume. It can replace multiple camera payloads and adapt to multiple scenarios. The resolution of the thermal imager can reach 640*512@30fps , is foldable, the maximum flight time is 41 minutes, and the image transmission range is 15 kilometers.
DJI Mavic 3T
The DJI Mavic 3T camera gimbal has 2 RGB camera lenses and 1 thermal imager. The visible light camera resolutions are 48MP and 12MP cameras respectively. The resolution of the thermal imager can reach 640*512@30fps. It is foldable. The maximum flight time is 45 minutes, and the image transmission range is 15 kilometers.
The top of the DJI Mavic 3T also has a replaceable payload interface, which can be installed with different drone accessories to achieve more functions, such as flashlights and speakers.
DJI P4 Multispectral
Designed for agriculture, the DJI P4 Multispectral features a 6-camera gimbal that combines different kinds of thermal and visual camera data.
DJI P4 multi-spectral drone is not foldable, visible light camera resolution is 2.1 MP, thermal imager resolution is 2.1 MP per spectrum, 6 camera arrays effectively detect good plant growth, maximum flight time is 27 minutes, image transmission range 8 hectares.
DJI Mavic 2 Enterprise Dual Edition
DJI Mavic 2 Enterprise Dual Edition has dual cameras, the resolution of the visible light camera is 48 MP, the resolution of the thermal imager can reach 640*512@30fps, it is foldable, the maximum flight time is 31 minutes, and the image transmission range is 13 kilometers.
The DJI Mavic 2 Enterprise Dual Edition is equipped with a DJI smart controller and a 5.5-inch screen. The drone package includes speakers, spotlights or beacon accessories, and optional RTK accessories, which can perform omnidirectional obstacle avoidance. It is a high-resolution thermal imaging The cheapest way to drone.
In conclusion
We do not announce the price of each thermal imaging drone in this article, we only explain the performance characteristics of each thermal imaging drone. Choose the thermal imaging drone that's right for you, not based on price.
Now, due to its advantages of high sensitivity, precise temperature measurement, and diverse applications, thermal imaging drones are gradually becoming important tools and equipment in all walks of life, bringing more convenience and safety to people's production and life. IR drones use infrared sensors to detect and identify targets. These Infrared drones can be used for a variety of missions, including surveillance, reconnaissance, search and rescue, and more.
